Cyclone Corrugated Plate Corner Tube Boiler Two Stage Steam Drying 50 t/h

Cyclone Corrugated Plate Corner Tube Boiler Two Stage Steam Drying Technology Steam Generation

Overview:

Through the "four-corner steel-free dynamic support system", the corner tube boiler achieves a double breakthrough in lightweight structure and heat transfer efficiency. Its heat recovery system supports the use of waste heat gradients. Combined with the fuel versatility design, it can quickly respond to complex working conditions in chemical, papermaking and other scenarios, achieve high environmental compatibility with low operation and maintenance costs, and form a sustainable solution for industrial thermal systems.

Product Image:

Product  Introduction:

The corner tube boiler can withstand ±10% pressure fluctuations and operate continuously for 30 days in a 4.4MPa high-pressure environment without attenuation. It integrates cyclone + corrugated plate two-stage steam drying technology (dryness ≥ 95%) and dynamically collects operating data to improve the accuracy of fault warning.

Technical Specifications:

Advantages:

(1)Suitable for extreme scenarios such as chemical industry and pharmaceutical industry, the steam dryness stability is ≥95% (competitive products ≤93%).

(2)The operation and maintenance cost of the whole life cycle is reduced by 40%, and the accuracy of fault prediction is significantly improved.

(3)The silicon carbide lined combustion chamber reduces furnace wear and ensures long-term operation reliability.
