Large Capacity Steam Supply Membrane Wall Boiler Short Installation Cycle High Temperature Resistance

Large Capacity Steam Supply Membrane Wall Boiler Short Installation Cycle High Temperature Resistance

Overview:

Combined with low-nitrogen combustion technology, membrane wall boilers achieve low NOx emissions and meet stringent environmental regulations. They are widely used in industries with strict environmental requirements such as pharmaceuticals and electronics. The compact structure saves plant space, and the quick-install design shortens the installation cycle, helping companies to quickly start production and achieve carbon neutrality goals.

Product Image:

Product Introduction:

Structure: Single-drum vertical membrane wall boiler, from top to bottom, there are drum, water-cooled wall, superheater, economizer (including main pipeline), and the drum is located at the top of the tail steel structure.
‌
Flue gas flow: Waste heat flue gas enters from the water-cooled wall radiation section → heat exchange with the superheater tube bundle → enters the subsequent treatment device → heat exchange through economizers 1, 2, and 3 step by step.
‌
Water circulation: Feed water passes through economizer 3 → 2 → 1 → drum → downcomer → membrane wall → upcomer → drum (steam-water separation → saturated steam → superheater → superheated steam → pipe network); drum water is supplemented to the lower header of the water-cooled wall through the downcomer to complete the natural circulation.

Technical Specifications:

Advantages:

This boiler is a vertical membrane wall waste heat boiler, the membrane wall is the heating surface: the steam drum is placed on the top of the steel structure. It is composed of platform escalator, steel frame, etc., with compact structure, high thermal efficiency and easy installation.

Applcation:
Suitable for high-temperature and high-pressure scenarios such as industrial waste heat recovery, large-scale central heating, and chemical production. Single-unit steam capacity ranges from 10 to 200 tons.
